MSI MPG X870E Carbon WIFI AM5 Socket, 4x M.2 slotu
Model: MPG X870E Carbon WIFI |
Socket Türü: Socket AM5 |
Vga Türü: PCIExp |
Ram Türü: DDR5 |
Çipset: AMD X870 |
BELLEK ÖZELLİKLERİ: |
4x DDR5 UDIMM, Maximum Memory Capacity 256GB |
Memory Support DDR5 8400+(OC)/ 8200+(OC)/ 8000+(OC)/ 7800(OC)/ |
7600(OC)/ 7400(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ |
6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ |
5000(JEDEC)/ 4800(JEDEC) MT/s |
Ryzen 9000 Serisi işlemciler için maksimum OC değerleri: |
• 1DPC 1R Max speed up to 8400+ MT/s |
• 1DPC 2R Max speed up to 6400+ MT/s |
• 2DPC 1R Max speed up to 6400+ MT/s |
• 2DPC 2R Max speed up to 4800+ MT/s |
GENİŞLETME SLOTLARI: |
3x PCI-E x16 slot |
PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU) |
PCI_E2 Gen PCIe 5.0 supports up to x4 (From CPU) |
PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset) |
DEPOLAMA: |
4x M.2 |
M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 |
M.2_2 Source (From CPU) supports up to PCIe 5.0 x4 |
M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 |
M.2_4 Source (From Chipset) supports up to PCIe 4.0 x4 |
4x SATA 6G |
SES: |
Realtek ALC4080 Codec |
7.1-Channel USB High-Performance Audio |
Supports up to 32-Bit/384 kHz playback on front panel |
Supports S/PDIF output |
LAN: |
1x Realtek 8126 5G LAN |
1x Realtek 8125 2.5G LAN |
WiFi: |
Wi-Fi 7 |
The Wireless module is pre-installed in the M.2 (Key-E) slot |
Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz/ 6GHz (320MHz) up to 5.8Gbps |
Supports 802.11 a/ b/ g/ n/ ac/ ax/ be |
Supports Bluetooth 5.4, MLO, 4KQAM |
USB: |
4x USB 2.0 (Ön) |
4x USB 5Gbps Type A (Ön) |
9x USB 10Gbps Type A (Arka) |
2x USB 10Gbps Type C (Arka) |
1x USB 20Gbps Type C (Ön) |
2x USB 40Gbps Type C (Arka) |
Form Factor: |
EATX Form Faktör |
Garanti: 36 Ay |
