MSI B650M PROJECT ZERO AM5 Socket
Model: B650M PROJECT ZERO |
Socket Türü: Socket AM5 |
Vga Türü: PCIExp |
Ram Türü: DDR5 |
Çipset: AMD B650 |
BELLEK ÖZELLİKLERİ: |
4x DDR5, Maximum Memory Capacity 256GB |
Memory Support DDR5 7600+(OC)/ 7400(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ |
6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ |
5200(OC)/ 5000(OC)/ 4800(JEDEC) MHz |
Max. overclocking frequency: |
? 1DPC 1R Max speed up to 7600+ MHz |
? 1DPC 2R Max speed up to 6400+ MHz |
? 2DPC 1R Max speed up to 6400+ MHz |
? 2DPC 2R Max speed up to 5400+ MHz |
GENİŞLETME SLOTLARI: |
1x PCI-E x16 slot |
- Supports x16 (For Ryzen? 7000 Series processors) |
- Supports x8 (For Ryzen? 7 8700G and Ryzen? 5 8600G processors) |
- Supports x4 (For Ryzen? 5 8500G processor) |
1x PCI-E x1 slot |
PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU) |
PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset) |
DEPOLAMA: |
2x M.2 |
M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices |
M.2_2 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices |
4x SATA 6G |
- M2_2 supports PCIe 4.0 x2 speed when Ryzen? 5 8500G is installed |
SES: Realtek ALC897 Codec |
Realtek ALC897 Codec |
7.1-Channel High Definition Audio |
Supports up to 32-Bit/384 kHz playback on front panel |
LAN: Realtek RTL8125BG 2.5Gbps LAN |
Form Factor: |
mATX |
243.84mmx243.84mm |
Garanti: 36 Ay |
