Type Intel Form Factor ATX 12V V2.31 |
Dimension (W x L x H) 150 x 170 x 86mm / 5.9 x 6.7 x 3.4 inch |
Input Voltage 90-264Vac (Auto Range) |
Input Current 10 - 5A |
Input Frequency Range 60 - 50Hz |
PFC Active PFC (>0.9) |
Power Good Signal 100-500ms |
Hold Up Time >17ms |
Efficiency 90% Typically |
MTBF >100,000 Hours |
Protection OVP/UVP/OPP/OTP/SCP |
Output Capacity 850W |
Operation Temperature 0~40°C |
Regulatory CE/TUV/TUV-SUDNRTL/FCC/GOST/CCC/BSMI/C-tick/KCC |
Fan Silent FDB 135mm |
Certifications 80 Plus Gold |
Bağlantılar: |
M/B 20+4 Pin Connector x 1 |
CPU 4+4 Pin x 2 |
PCI-e 6+2 Pin x 6 |
SATA x 9 |
4 Pin Peripheral x 4 |
4 Pin Floppy x 1 |
Garanti Süresi : 24 Ay |
